Yamaha DCFXE3PRO
Yamaha DCFXE3PRO

Yamaha DCFXE3PRO

Yamaha DCFXE3PRO is designed based through the advanced technology having the application collaborated and visualized by the Internet.  Basically, this has been built to utilize as a standard remote lesson that takes simultaneously diagonally to any topographical distances. Mainly, the Yamaha DCFXE3PRO is crucial for teaching and entertainment applications, which can be synchronized with an unconditionally defined replica by the piano.

  • Play whisper-soft sounds
  • Internet Direct Connection (IDC)
  • Uninterrupted streams of music over 25 different channels
  • Angled speakers
  • Easy-to-see display panel (organic electro-luminescent display)
  • CD synchronize recording
  • Remotely can be used through an iPhone, iPod touch or an iPad
  • Amplified speaker systems
  • Sleek and elegant controls
  • Control Disklavier functions
Soundboard: Material Premium Woods
Number of Keys 88
Key Surfaces White: Ivorite / Black: WPC
Pedal Damper/Sostenuto/Shift
Hammer Sensors Noncontact optical fiber/grayscale shutter sensing system for 88 keys (senses the key position, keying velocity, and key releasing velocity)
Pedal Sensors Damper & Shift pedals: Noncontact optical position-sensing Sostenuto pedal: Optical ON/OFF detection sensing system
Key Drivers DSP servo drive system (servocontrolled solenoids)
Pedal Drivers DSP servo drive system (servocontrolled solenoids)
Hammer CX Series Special
Caster Double Caster
Frame V-pro
Back Post 4
Lid Prop Safety Stop Yes
Lid/Fallboard Locks Yes
Soft-Close Fallboard Yes
Piano Silencing Mechanism Motor-driven hammer shank stopper
Tone Generating Technology Advanced Wave Memory 2 (AWM2)
Number of Polyphony 32
Featured Voices Normal Voices: 676 Drum Voices: 21 kits total
Overall Control Tunings Set at A=440, tunable+/-50cents in 1-cent increment
Internal Memory 128MB
CD Audio CD (ISO 9600-complaints), Data CD (ISO 9600-Level1-complaint)
USB Flash Memory (Optional) Yamaha does not assure the operation of the commercially available USB flash memories.
USB Hard Disk (Optional) FAT 32 format (Yamaha does not assure the operation of the commercially available USB hard disks).
USB Floppy Disk Drive (Optional) Yamaha UD-FD01 floppy drive (Yamaha does not assure the operation of other commercially available USB floppy drives)
Power Requirements Local AC current, 100-240V, 50/60Hz
Included Accessories Control Unit (1), control unit suspension bracket (1), monitor speaker (2), monitor speaker installation kit (1), speaker cord (2), remote control (1), battery for remote control (2), sample Pianosoft CD software (2), quick reference (1), operation manual (1), stereo headphones (1).
Height 40.5”
Width 63”
Length 9”
Weight 1190lbs.
